This 18AWG 1 pair cable is a Belden 8719 equivalent, designed for low-voltage signal, audio and instrumentation applications where dependable screened performance is essential. It is widely used in sound and broadcast systems, analogue audio installations, and control/instrumentation wiring across commercial and industrial environments.
The cable features tinned copper conductors for enhanced corrosion resistance and easier termination, making it well suited to installations where long-term reliability is critical. An overall foil screen with integrated drain wire provides effective protection against electromagnetic interference (EMI), ensuring stable signal transmission on balanced audio and data circuits in electrically noisy areas.
The LSZH (Low Smoke Zero Halogen) outer sheath makes it suitable for indoor installations where reduced smoke and toxic emissions are required in the event of fire. The cable is CPR rated to Euroclass B2ca-s1a,d0,a1, supporting compliance in public and commercial building projects.
Specification
| AWG Size |
16
|
| Pairs |
1 Pair |
| Conductor Material |
Tinned Copper |
| Overall Screening |
Aluminium foil with drain wire |
| Outer Sheath Material |
LSZH |
| CPR Rating |
Euroclass B2ca-s1a,d0,a1 |
Typical Applications
- Sound and broadcast audio systems
- Analogue signal transmission
- Instrumentation and control wiring
- Low-Voltage Data & Serial Communication
As a Type 8719 Belden equivalent, this cable is compatible with installations specifying that standard, subject to confirmation of exact project requirements. Suitable for fixed internal wiring where screened 16AWG twisted pair cable is specified.
