Description
Fully Ex-certified GRP junction box with 6 x WDU 2.5mm terminals (linked in pairs), dual ATEX & IECEx approved for -50°C to +55°C (T5) and -50°C to +40°C (T6). Features pre-drilled plugged entries, Zintec earth plate, and external stainless steel earth stud. Supplied with M20 blanking and travel plugs.
Specification
| Cable Entry | 4 x M20 |
| Certification Code |
Ex eb IIC T Gb (Increased Safety), Ex ta IIIC T°C Da (Dust Ignition) |
| Colour |
Grey |
| Depth | 90mm |
| Dimensions | (H)120 mm x (W)122 mm x (D)90 mm |
| IP Rating |
IP66 / IP67 |
| Material |
GRP |
| Number of Terminals |
6 |
| Standards | CML 20ATEX3009X, IECEx CML 20.0003X, CML 21UKEX3471X |
| Terminal Capacity |
2.5mm² |
| Terminal Type |
Screw |
| Weight | 1.14kg |
| Zone Rating |
Zone 1 Zone 2 Zone 21 Zone 22 |
