High adhesion and high pliability are the hallmarks of Brady’s nylon cloth (B-499) label material and M21-750-499 label cartridge. It’s designed to meet a broad array of identification requirements from control panels to liquid nitrogen environments.
- The clear wraparound size is 9.52 mm.
- Parts will print with black text
- Not compatible with the ID PAL Printer.
Specifications
| Brady Part Code |
M21-750-427 |
| Total Qty Per Pack |
1 Tape / Box |
| Application |
Data and telecommunications labelling, Electrical labelling, General identification, Wire and cable labelling
|
| Ribbon Series |
R4300 |
| Size - Length (m) |
4.30 m |
| Size - Width (mm) |
19.05 mm |
| Max. Wire/Cable Diameter (mm) |
3.00 mm |
| Min. Wire/Cable Diameter (mm) |
2.00 mm |
| Wire Diameter Range (mm) |
2.00 mm - 3.00 mm |
| Wire Gauge Range |
20 AWG - 12 AWG |
| Printable Area Dimensions |
9.53 mm W |
| Printable Area - Width (mm) |
9.53 mm |
| Roll Length |
4.27 m |
| Vial/Tube (ml) |
50.0 mL |
| Dimensions |
19.05 mm (W) x 4.30 m (L) |
| Brady Material Number |
B-427 |
| Brady Material Type |
Self-laminating Vinyl |
| Material Properties |
Flame-retardant, Self-laminating
|
| Thickness (mm) |
0.102 mm
|
| Colour |
Black on White
|
| Environment |
Freezer, Liquid Nitrogen
|
| Max. Service Temp. °C |
70 °C |
| Min. Service Temp. °C |
-70 °C |
| Adhesive |
Permanent Acrylic |
| Finish |
Matt |
| Surface |
For smooth & textured/rough surfaces
|
| Label Properties |
Self-laminating & Wrap Around
|
| Resistance Properties |
Abrasion-resistant, Chemical-resistant, Humidity-resistant, Oil-resistant, Smear-resistant, Water-resistant, Weather-resistant
|
| Print Technology |
Thermal Transfer
|
| Smart Cell |
Yes |
| Printer Compatibility |
BMP21, BMP21-LAB, BMP21-PLUS, IDPAL, LABPAL, M210, M210-LAB, M211
|
| UNSPSC |
55121612 |
| RoHS Compliance Status |
Compliant with Directive 2011/65/EU and 2015/863 |
| REACH SVHC Status |
Part does not contain an SVHC |
